Product type: Dimensions cabinet: Installation:
Type of door:
Locking:
Finish:
Colour:
Mounting plate:
Weight (kg):
Materials:
Thickness:
Sealing gasket:
Door material:
Capacity:
Max. cabinet load:
Max. mounting plate load: Max. door load:

Technical data:

Degree of protection:
NEMA degree of protection: Resistance to impact: Ambient temperature range: Maximum operating voltage:

Certificates and standards:

Wall-mounting cabinet
(AxBxC) 500x500x300 mm
Surface
Single opaque door. Reversible
5-mm double-bit lock - Two 1-points lock
Coated with primer, and hardened polyester paint, textured, with UV protection RAL 7035
With flat mounting plate. 2-mm galvanised sheet steel
16,6
Cold-rolled steel EN 10130+A1
Enclosure: 1,2 mm. Door: 1,2 mm. Cable entry lid: 2 mm.
Injected polyurethane sealing gasket

225 kg 200 kg 25 kg

IP66
NEMA 1, 12, 4
IK10
-25 oC / +60 oC
1000 V AC / 1500 V DC

Directive: Standards: Certificates:

Codes:

EAN:
Customs tariff number: ETIM 8.0:

2014/35/EU
IEC 62208, IEC 61439-1 UL508A

8431044490571 85.38.10.00 EC000261
