Switch di rete con 8 porte Gigabit PoE e 2 Uplink Gigabit RJ45.

La potenza totale PoE è 120 Watt, massimo 30 Watt per porta.
Standard 802.3AF,802.3AT
Porte
Porte 8*10/100/1000 Base-T +2* 1000Base-X
Alimentazione AC220V
Indicatori LED P ,9,10,link/active ,speed
Tipi di cavo e distanze di trasmissione
Rame Twisted-pair 0-100m
Fibra Mono mode 20/40/60/80/100KM
Fibra Multimode 550M

Caratteristiche di rete
Ring topology No Support
Star topology Support
Bus topology Support
Tree Topology Support

Specifiche elettriche
input AC 100-240V 50/60Hz
Consumo totale =130W


PoE caratteristiche
Standard 802.3AF,802.3AT
PoE Pin 12+ 36-
Porte 1-8
Potenza massimo per porta 30W
Potenza totale PoE 120W
DIP Switch
1_ AI PoE
2_ 1-8 Ports support 250m PoE & Data transmission
3_ 1-8 Ports Vlan isolation
4_ 1-8 Ports restain data storm within 5%

Dati
Switching capacity 20G
Packet forwarding rate 14.88Mpps
MAC address table 4K
Buffer 2K
Forwarding delay <5us
MDX/MIDX Support

Dati ambientali
Temperatura operativa -10 +50
Immagazzinamento -40 +70
Umidità relativa 5% 95% non-condensing
Thermal methods Fan less design , self cooling
Aspettativa di vita MTBF100000 Hours

Protezioni
Surge protection of Ethernet port IEC 61000-4-5 Level 44/2KV10/700us
DIP IEC 61000-4-11 Level3 10V
ESD IEC 61000-4-2 Level 4 8K/15K
Protezione dalla caduta 0.5m

Dimensioni meccaniche
dimensione 220*162*37mmLxWxH
installazione Desk
Peso 0.82KG
